FitWeld Evo 300 [11/20] Wire guide tubes and wire feed rolls

2.5.5 Wire guide tubes and wire feed rolls

Make sure that you select appropriate wire feed rolls/groove type, welding gun contact tip

and wire liner for the ller wire used.

Kemppi feed rolls and gun liners are colour-coded in order to make identication easy.

Wire guide tubes

ø mm outlet tube inlet tube

Ss, Al, (Fe, Mc, Fc)

plastic

W003963 W003962

Fe, Mc, Fc

metal

W003881 W003536

Wire feed rolls, plastic

ø mm lower upper

Fe, Ss, (Al, Mc, Fc)

V-groove

0.8 – 0.9 W001047 W001048

1.0 W000675 W000676

1.2 W000960 W000961

Fc, Mc, (Fe)

V-groove, knurled

1.0 W001057 W001058

1.2 W001059 W001060

Al, (Fc, Mc, Ss, Fe)

U-groove

1.0 W001068 W001067

1.2 W001070 W001069

Wire feed rolls, metal

ø mm lower upper

Fe, Ss, (Al, Mc, Fc)

V-groove

0.8 – 0.9 W006074 W006075

1.0 W006076 W006077

1.2 W004754 W004753

Fc, Mc, (Fe)

V-groove, knurled

1.0 W006080 W006081

1.2 W006082 W006083

Al, (Fc, Mc, Ss, Fe)

U-groove

1.0 W006088 W006089

1.2 W006090 W006091
