Zongshen T 30 [41/41] 前操电起动 electric starting remote control

位置数量零部件编码零件名称中文零件名称英文备注

Pos. Qty. ZS code Chinese Description English Description Remark

前操电起动/ELECTRIC STARTING(REMOTE CONTROL)

Fig. 12-51 1 16020-C96-0000 电瓶负极线 Negative cable to battery

Fig. 12-52 1 09012-D05-0000 面板堵头 Plug

Fig. 12-53 1 20200-C96-0000 线束前操电启动 Coil harness

Fig. 12-54 1 B0007001050040000 螺钉 GB/T 70.1 M5×40-A4-70 Screw M5x40

Fig. 12-55 1 B0009500050000J00 垫圈 GB/T 95 5-A4 Washer 5

Fig. 12-56 1 20301-C96-0000 接插头罩 Rectifier connector cover

Fig. 12-57 1 20302-C96-0000 接插头座 Rectifier connector

Fig. 12-58 1 20100-C96-0000 整流器 Rectifier

Fig. 12-59 1 B0088901050000600 螺母 GB/T 889.1 M5-A4-70 Selflocking nut M5

Fig. 12-60 1 B0007001050016000 螺钉 GB/T 70.1 M5×16-A4-70 Screw M5×16 液压升降

Fig. 12-61 1 11406-C96-0000 继电器安装支板 Fixing plate 液压升降

Fig. 12-62 2 B0088901050000000 螺母 GB/T 889.1 M5-A4-70 Selflocking nut M5 液压升降

Fig. 12-63 3 B0085900050000000 垫圈 GB/T 859 5-SUS304 Spring washer 5 液压升降用3

件，普通前操用

1件

Fig. 12-64 4 20500-C96-0000 起翘器继电器 relay 液压升降

Fig. 12-65 1 10217-C96-0000 护线橡胶圈 Fairled 液压升降

Fig. 12-66 1 16210-C96-0000 启动继电器 Solenoid starter 液压升降
