Zongshen T 30 [5/41] 底罩顶罩 basin hood

位置数量零部件编码零件名称中文零件名称英文备注

Pos. Qty. ZS code Chinese Description En

lish Description Remark

Fig 01-01

T09999-0094-0000

字样贴花

“

”

红色

Decal power 25 HP

底罩顶罩/BASIN & HOOD

Fig

01-01

T09999-0094-0000

字样贴花

红色

Decal

power

Fig. 01-01 2 T09999-0095-0000

字样贴花“30” 红色

Decal power 30 HP

Fig. 01-02 1 T09999-0088-0000 顶罩左右侧贴花红色 Lateral decal -right &left

Fig. 01-03 1 T09999-0087-0000 顶罩正上方贴花红色 Decal "ZS"

Fig. 01-04 1 T09999-0109-0000 阅读说明书贴花——中文 Reading owner's manual decal

Fig. 01-04 1 T09999-0110-0000 阅读说明书贴花——英文 Reading owner's manual decal

Fig. 01-05 1 T09999-0207-0000 两冲程加燃烧机油贴花中文 Decal 2 stroke outboard oil

Fig. 01-05 1 T09999-0208-0000 两冲程加燃烧机油贴花英文 Decal 2 stroke outboard oil

Fi 01 06

08001 C96 0000

顶罩本体

手起动

Hdbd lti ti

08001

C96

0000

顶罩本体

—

手起动

y -e

c s

Fig. 01-06 1 08001-C96-0000 顶罩本体——电启动 Hood body -electric staring

Fig. 01-07 1 08003-C96-0000 顶罩提扣 Motor lift handle

Fig. 01-08 6 B1261801050100J00 抽芯铆钉 GB/T 12618.1 5×10 Rivet 5×10

Fig. 01-09 1 09001-C96-0000 胶条 Basin-capote profile

Fig. 01-10 2 B0578300060016000 螺栓 GB/T 5783 M6×16-A4-70 Bolt M6x16

Fig. 01-11 2 08005-C96-0000 挂钩销支撑 Pin register support

Fig. 01-12 2 08006-C96-0000 挂钩销组合 Pin register

Fig. 01-13 2 B0009500060000J00 垫圈 GB/T 95 6-A4 Washer 6

Fig. 01-14 2 B0617500050000800 螺母 GB/T 6175 M6-A4-70 Nut M6

Fig. 01-15 1 08000-C96-0000 顶罩总成（1～15） complete hood

（from 1 to 15）

Fig. 01-16 1 13011A-C96-0000 手把握把套 Handle cover

Fig. 01-17 1 13012-C96-0000 手柄握把塞 Handle plug

Fig. 01-18 1 13013-C96-0000 手把弹簧 Spring

Fig. 01-19 1 T09999-0033-0000 油门大小指示贴花 Decal "MAX START-MIN"

. 01-20 1 13011B-C96-0000

手柄握把

Handle

手柄握把

Fig. 01-21 1 13015-C96-0000 手把油门杆 Handle rod

Fig. 01-22 1 13016-C96-0000 操舵手柄 Handle body

Fig. 01-23 2 13003-C96-0000 手把垫片 Washer

Fig. 01-24 2 13001A-C96-0000 手把减振连接轴 Shock absorber gudgeon

Fig. 01-25 2 13001B-C96-0000 手把减振套 Shock absorber

Fig. 01-26 2 B0087904030014C00 销 GB/T 879.4 3×14-C Elastic pin 3×14

Fig. 01-27 2 09008-C96-0000 尼龙垫片 Nylon washer

Fig 01-28

13018-C96-0000

油门连接齿

Gear joint

Fig

01-28

13018-C96-0000

油门连接齿

Gear

joint

Fig. 01-29 2 13017-C96-0000 油门杆衬套 Bushing

Fig. 01-30 1 13004-C96-0000 手把连接盖 Support cover

Fig. 01-31 2 B0578300060020000 螺栓 GB/T 5783 M6×20-A4-70 Bolt M6x20

Fig. 01-32 1 B000700108004070U 螺钉 GB/T 70.1 M8×70-A4-70 Screw M8x70

Fig. 01-33 1 B0007001080035000 螺钉 GB/T 70.1 M8×35-A4-70 Screw M8x30

Fig. 01-34 1 13005-C96-0000 手把支撑座 Handle support

Fig. 01-35 1 13006-C96-0000 油门传动杆 Handle shaft

Fi 01 36

13000 C96 0000

操舵手柄组件

Clttihdl

13000

C96

0000

操舵手柄组件

omp

e s

eer

Fig. 01-37 1 09009-C96-0000 发动机底罩垫片 Engine-cover gasket

Fig. 01-38 1 09102-C96-0000 衬套 Bushing

Fig. 01-39 1 90101-10100000200 O形圈10×2 O ring 10×2

Fig. 01-40 1 09003-C96-0000 后挂钩 Pin with back hook

Fig. 01-41 2 11206-C96-0000 衬套 Bushing

Fig. 01-42 1 09101-C96-0000 底罩-手起动 Basin-manual staring

Fig. 01-42 1 09101-C96-0100

底罩-后操电启动

Basin-electric staring(handle control)

Fig. 01-42 1 09101-C96-0101

底罩-后操电启动液压升降

Basin-electric staring(handle control & H.P.)

Fig. 01-42 1 09101-C96-0400

底罩-前操电启动

Basin-electric staring(remote control)

Fig. 01-42 1 09101-C96-0500 底罩前操电启动液压升降

Basin-electric staring(remote control & H.P.)

Fig. 01-43 2 09007-C96-0000 垫片 Washer

Fig. 01-44 2 09008-C96-0000 尼龙垫片 Nylon washer

Fig. 01-45 1 09005-C96-0000 后挂钩手柄 Back lever

Fig. 01-46 2 B0087904040020C00 销 GB/T 879.4 4×20-C Elastic pin 4×20

Fig. 01

14104

C96

0000

铜垫

Cuprum Washer

Fig.

01 47

14104 C96 0000

铜垫

Cuprum

Washer

Fig. 01-48 4 B0007001050020000 螺钉 GB/T 70.1 M5×20 A2-70 Screw M5x20

Fig. 01-49 1 14103-C96-0000 消声器 Outlet trap

Fig. 01-50 1 09010-C96-0000 底罩水下垫片 Cover - shaft gasket
