Zongshen T 30 [9/41] 汽缸体 cylinder block

位置数量零部件编码

零件名称中文零件名称英文备注

Pos. Qty. ZS code

Chinese Description English Description Remark

Fig. 02-01 10 B0578900080070A0U

螺栓 GB/T 5789 M8×70-10.9-达克罗

Screw TE M8x70

Fig. 02-02 10 B0009500080000J00 垫圈 GB/T 95 8 Washer 8

Fig. 02-03 1 01003-C96-0000 汽缸盖罩 Cylinder head

Fig. 02-04 1 01004-C96-0000 汽缸盖罩垫 Cylinder head gasket

Fig. 02-05 1 01001-C96-0000 汽缸盖 Bear head 25HP

Fig. 02-05 1 01001-C96-0100 汽缸盖 Bear head 30HP

Fig. 02-06 1 01007-C96-0000 节流阀 Thermostat

Fig. 02-07 1 01008-C96-0000 节流阀垫 Thermostat gasket

Fig. 02-08 1 01006-C96-0000 节流阀盖垫 Thermostat cover gasket

Fig. 02-09 1 01005-C96-0000 节流阀盖 Thermostat cover

Fig. 02-10 6 B000700106002570U

螺钉 GB/T 70.1 M6×25-8.8-达克罗

Screw M6x25

Fig. 02-11 1 02001-C96-0000 左排气外罩 Exhaust cover

Fig. 02-12 12 B057830006002570U

螺栓 GB/T 5783 M6×25-8.8-达克罗

Bolt M6x25

Fig. 02-13 12 B0009500060000J00 垫圈 GB/T 95 6-A4 Washer 6

Fig. 02-14 4 02004-C96-0000 排气外罩衬垫 Exhaust gasket

Fig. 02-15 2 02003-C96-0000 排气外罩隔板 Exhaust separator

Fig. 02-16 1 01002-C96-0000 汽缸床 Head gasket

Fig. 02-17 1 02009-C96-0000 出水管 Water pipe

Fig. 02-18 2 02008-C96-0000 水管接头 Connector

Fig. 02-19 8 B0088900080000000 螺母 GB/T 889.1 M8-A4-70 Selflocking nut M8

Fig. 02-20 6 B0009500080000J00 垫圈 GB/T 95 8 Washer 8

Fig. 02-21 6 02013-C96-0000 双头螺栓M8 Cylindric stud M8

Fig. 02-22 1 02002-C96-0000 右排气外罩 Exhaust cover - pump

Fig. 02-23 1 02110-C96-0000 汽缸体组件 Cylinder block

Fig. 02-24 2 B008610106000000U

内齿锁紧垫圈 GB/T 861.1 6-达克罗

Washer 6

Fig. 02-25 2 B000700106002570U

螺钉 GB/T 70.1 M6×25-8.8-达克罗

Screw M6x25

Fig. 02-26 2 02010-C96-0000 通油管接头 Recovery connector

Fig. 02-27 1 02011-C96-0000 通油管 Recovery pipe

Fig. 02-28 1 02007-C96-0000 曲轴上轴承座衬垫 Upper crankcase head gasket

Fig. 02-29 2 FB03004007FPM 油封 TC 30×40×7 Oil seal RP 30 x40 x 7

Fig. 02-30 1 02005-C96-0000 曲轴上轴承座 Upper crankcase head

Fig. 02-31 4 B026720008002090U

螺钉 GB/T 70.3 M8×20-10.9达克罗

Screw M8x20

Fig. 02-32 1 0300A-C96-0000 飞轮垫圈 Washer

Fig. 02-33 1 03010-C96-0000 飞轮螺母 Selflocking nut M16×1.5

Fig. 02-34 1 03008-C96-0000 曲轴上轴承垫片 Shim

Fig. 02-35 1 03100-C96-0000 曲轴连杆总成 Complete driving shaft

Fig. 02-36 2 92102-K182222FKIV1A 连杆小头滚针轴承 Retainer and needle

Fig. 02-37 4 03004-C96-0000 连杆小头侧垫 Shoulder

Fig. 02-38 4 03005-C96-0000 活塞销挡圈 Gudgeon retainer

Fig. 02-39 2 03003-C96-0000 活塞销 Gudgeon

Fig. 02-40 2 03002-C96-0000 活塞 Piston

Fig. 02-41 4 03006-C96-0000 活塞环 Piston ring

Fig. 02-42 3 03007-C96-0000 挡油环 FEY ring

Fig. 02-43 1 B0089401300000000 挡圈 GB/T 894.1 30 Seeger ring 30

Fig. 02-44 1 02006-C96-0000 油封壳体衬垫 Lower crankcase head

Fig. 02-45 1 FB03005010FPM 油封 TC 30×50×10 Oil seal RP 30 x 50 x10

Fig. 02-46 1 02210-C96-0000 单向阀 Valve

Fig. 02-47 1 02201-C96-0000 油封壳体本体 Lower crankcase head

Fig. 02-48 1 02200-C96-0000 油封壳体组件 Complete lower crankcase head

Fig. 02-49 4 B0007001080025000 螺钉 GB/T 70.1 M8×25-A4-70 Screw M8x25

Fig. 02-50 1 05910A-C96-0000 簧片阀座A Leaf valve support A

Fig. 02-51 1 05910B-C96-0000 簧片阀座B Leaf valve support B

Fig. 02-52 2 05903-C96-0000 定位销φ5×10 Pin 5×10

Fig. 02-53 8 05901-C96-0000 簧片 Leaf

Fig. 02-54 4 05902-C96-0000 簧片挡板 Leaf valve retainer

Fig. 02-55 8 B057890004000870U 螺栓 GB/T 5789 M4×8 Screw TEF M4x8

Fig. 02-56 2 B0007001050020000 螺钉 GB/T 70.1 M5×20-A4-70 Screw M5X20

Fig. 02-57 4 B0009500080000J00 垫圈 GB/T 95 5-A4 Washer 5

汽缸体/CYLINDER BLOCK

Zongshen T 30 [9/41] 汽缸体 cylinder block
