- 5 -
1.4 Print Specifications
Print Specifications
203 dpi models
300 dpi models
600 dpi models
Print head resolution
(dots per inch/mm)
203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Printing method
Thermal transfer and direct thermal
Dot size
(width x length)
0.125 x 0.125 mm
(1 mm = 8 dots)
0.084 x 0.084 mm
(1 mm = 12 dots)
Print speed
(inches per second)
2,3,…14 ips
Up to 14 IPS
2,3,…12 ips
Up to 12 IPS
Max. print width
104 mm (4.09”)
Max. print length
1000” (25,400 mm)
450” (11,430 mm)
100” (2,540 mm)
Printout bias
Vertical: 0.7 ~ 1mm.
1.5 Ribbon Specifications
Ribbon Specifications
Ribbon outside diameter
Max. 90 mm OD
Ribbon length
600 m
Ribbon core inside diameter
1“ (25.4 mm)
Ribbon width
25.4 mm ~ 114.3 mm (1”~4.5”)
Ribbon wound type
Ink coated outside wound, ink coated inside wound
Ribbon end type
Transparency
1.6 Media Specifications
Media Specifications
Media roll
capacity
Max. 8” (203.2 mm) OD; 1.5” or 3” ID core, Rewind 3” only
Media core
diameter
3” (76.2 mm) or 1.5” (38.1 mm) ID core
Media type
Continuous, die-cut, black mark, fan-fold, notch
Media wound type
Outside wound
Media width
20 mm ~ 114 mm (0.78“ ~ 4.49“)
Media thickness
0.06 mm ~ 0.28 mm
Label length
5 mm ~ 25,400 mm (0.20”
~ 1,000”)
5 ~ 11,430 mm (0.20” ~
450”)
5 ~ 2,540 mm (0.20” ~
100”)
Black mark
Min. 8 mm (W) x Min. 2 mm (H)
Gap height
Min. 2 mm
