TSC MH240 [30/73] Remove used ribbon

- 21 -

3.3 Remove Used Ribbon

1. Break the ribbon between ribbon

guide plate and the ribbon rewind

spindle.

2. Push the ribbon release button and

slide the ribbon off to release the

ribbon on the ribbon rewind spindle at

the same time.

SLIDE OFF
