22
4.1.2 Printer Initialization
Printer Initialization will restore printer settings to defaults.
Default settings are listed as below.
Item
Default Value
Cleared by
Initialization
Property Saved
when Turning off
Power
Mileage
N/A
No
Yes
Check Sum
N/A
No
Yes
Serial Port
9600,n,8,1
Yes
Yes
Code Page
437
Yes
Yes
Country Code
001
Yes
Yes
Tear Mode
On
Yes
Yes
Peel Mode
Off
Yes
Yes
Cutter Mode
Off
Yes
Yes
Offset
0
Yes
Yes
Reference Point
0,0
Yes
Yes
Print Direction
1
Yes
Yes
Speed
4 inch/sec
Yes
Yes
Density
07
Yes
Yes
Label Size
4 x 2.5”
Yes
Yes
Gap/Bline Sensor
Gap Sensor
Yes
Yes
Gap(Bline)
0.12” (3 mm)
Yes
Yes
Transparency
Will be reset. Need
to re-calibrate the
gap sensor
Yes
Yes
Ribbon Sensor
Sensitivity
1
Yes
Yes
LCD Language
English
Yes
Yes
Aux. LED
Off
Yes
Yes
Aux. Buzzer
Off
Yes
Yes
Download Files
N/A
No
Yes
RTC
N/A
No
No
Please follow the steps below to initialize the printer:
1. Turn off the printer power.
