Start-up and test of installation

When the LED remains blue all of the time, it is time to try out the robot lawnmower.

Lift the robot up and set the main switch to ON.

Now place the robot on a random spot on the lawn. Press the STOP button on the top of

the robot.

The cover will open automatically.

Enter the PIN code. The code will be 0000, which is factory-set (you can enter a personal

pin code later on, read the chapter “PIN code”).

Find the “HOME” button and press it. You must then manually close the top cover.

The robot will start to move. It will find its way back to the charging station, by finding the

boundary cable, and then moving in an anticlockwise direction. It will dock with the

charging station and start to recharge the battery.

If the robot does not dock properly with the charging station or approaches it at an angle,

then most likely the docking station’s position will need to be adjusted.

Now the robot will automatically begin to charge up, and the following symbols will flash in

the display, until it is fully charged.

Main switch

OFF

(Button pressed out)

(Button pressed in)
