- 10 -
Hardware Installation
1-2 ProductSpecications
CPU Support for 7th and 6th generation Intel
®
Core
™
i7 processors/
Intel
®
Core
™
i5 processors/Intel
®
Core
™
i3 processors/
Intel
®
Pentium
®
processors/Intel
®
Celeron
®
processors in the LGA1151 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel
®
Z270 Express Chipset
Memory 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than the size of
the physical memory installed.
Dual channel memory architecture
Support for DDR4 2400/2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
SupportforExtremeMemoryProle(XMP)memorymodules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor+Intel
®
Thunderbolt
™
3 Controller:
- 1 x Intel
®
Thunderbolt
™
3 connector, supporting DisplayPort and Thunderbolt
™
video outputs and a maximum resolution of 4096x2304@60 Hz
* Because of the limited I/O resources of the PC architecture, the number of
Thunderbolt
™
devices that can be used is dependent on the number of the PCI
Express devices being installed. (Refer to Chapter 1-7, "Back Panel Connectors,"
for more information.)
* Support for DisplayPort 1.2 version.
Integrated Graphics Processor-Intel
®
HD Graphics support:
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version.
Integrated Graphics Processor+MegaChips MCDP2800 chip:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.0 version. (Requires the latest Intel
®
graphics driver from the
GIGABYTE website.)
Support for up to 3 displays at the same time
Maximum shared memory of 1 GB
Audio Creative
®
Sound Core 3D chip
2 x JRC NJM2114 and 1 x TI Burr Brown
®
OPA2134operationalampliers
Support for Sound Blaster ZxRi
HighDenitionAudio
2/5.1-channel
Support for S/PDIF Out
LAN 2 x Rivet Networks Killer
™
E2500 LAN chips (10/100/1000 Mbit)
Wireless
Communication
module
Killer
™
Wireless-AC 1535
Wi-Fi 802.11 a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
Bluetooth 4.1
Support for 11ac wireless standard and up to 867 Mbps data rate
* Actual data rate may vary depending on environment and equipment.
