Gigabyte GA-Z270X-Gaming 9 [129/144] 2 5 using the voice recorder

- 129 -

Appendix

Step 3:

Open the Sound Blaster ZxRi Control Panel and go

to the Mixer page. In the REC section, you can use

the What U Hear slider to set the volume.

6-2-5 Using the Voice Recorder

A. Recording Audio

1. To begin the recording, click the Record icon .

2. To stop the recording, click the Stop recording icon .

B. Playing the Recorded Sound

The recordings will saved in Documents>Sound Recordings. Voice Recorder records audio in MPEG-4 (.m4a)

format.Youcanplaytherecordingwithadigitalmediaplayerprogramthatsupportstheaudioleformat.

After setting up the audio input device, to open the

Voice Recorder, go to the Start menu and search for

Voice Recorder.
