Box Contents
5
GA-Z270X-Gaming 9 motherboard
5
Motherboard driver disk
5
User's Manual
5
Quick Installation Guide
5
Six SATA cables
5
I/O Shield
5
One Wi-Fi antenna
5
One Wi-Fi antenna retention cover
5
One GC-SLI23P SLI bridge connector
5
One 3-Way SLI bridge connector
5
One 4-Way SLI bridge connector
5
One 2-Way CrossFire bridge connector
5
Two RGB (RGBW) LED strip extension cables
5
One Accent Lighting LED Strip
5
Two thermistor cables
5
One G Connector
5
Two Velcro Cable Ties
5
One pack of back I/O dust covers
The box contents above are for reference only and the actual items shall depend on the product package you
obtain. The box contents are subject to change without notice.
Optional Items
2-port USB 2.0 bracket (Part No. 12CR1-1UB030-6*R)
eSATA bracket (Part No. 12CF1-3SATPW-4*R)
3.5" Front Panel with 2 USB 3.1 Gen 1 ports (Part No. 12CR1-FPX582-2*R)
HDMI-to-DVI adapter (Part No. 12CT2-HDMI01-1*R)
