Operation LE MINI

• Fit the nozzle appropriate to the use.

Danger – can cause burns! Do not touch the heating element tube and nozzle while they are hot. Allow

the device to cool down before replacing the nozzle / reflector.

• Adjust pressure reduction valve in accordance with the technical details on (see technical data, max. pressure).

• Connect the air supply by means of the pneumatic hose

• Adjust the air flow by means of an air flow controller or pressure reduction valve

ATTENTION: Comply with minimum air volume as per technical data.

• Remove tool from mains • Check air flow

• Check air supply • Re-connect tool to the mains

• Check air volume

Operation LE MINI SENSOR

• Fit the nozzle appropriate to the use.

Danger – can cause burns! Do not touch the heating element tube and nozzle while they are hot. Allow

the device to cool down before replacing the nozzle / reflector.

• Adjust pressure reduction valve in accordance with the technical details on (see technical data, max. pressure).

• Connect the air supply by means of the pneumatic hose

• Adjust the air flow by means of an air flow controller or pressure reduction valve

Function tool protection

• If the tool overheats, the heating is switched off by means of the converter. The switching- off can be evaluated

by the customer using connection X5 (Circuit Diagram, page 15).

Function analogue interface

• A galvanically isolated signal proportional to the air temperature is available to the customer by means of the

4.20 mA passive current loop.

Value range: 4 mA corresponds to 0 °C / 32 °F

Measures to be taken if the heating element or tool protection trips

• Remove tool from mains (LINE/MAINS). The electronics are automatically reset after 5 seconds
