Cybex Pallas M Manhattan Grey [13/84] Adapting to body size

In order to optimally adapt the CYBEX PALLAS M to your child’s body size, a seat

insert (i) has been provided as standard and is already inserted under the seat cover.

Note! Only an optimally adjusted headrest (e) can offer your child maximum

protection and comfort while ensuring that the diagonal belt can be tted smoothly (f).

The height of the CYBEX PALLAS M can be adjusted to one of twelve positions.

ADAPTING TO BODY SIZE

REMOVING THE ADDITIONAL SEAT INSERT

• We recommend using this additional seat insert (i) for children aged 9 to 24

months.

• From the age of 25 month, the seat insert (i) is no longer necessary.

• The seat can then be adjusted to your child’s body simply by using the adjustable

headrest (e). To do this, pull the adjustment level (h) upwards to unlock the

headrest (e).

• Adjust it so that there is space for two ngers between the lower edge of the

headrest (e) and the shoulder of the child.

1. Release the front push buttons of the seat cover from the seat cushion (d).

2. Pull the fabric cover from the cover guides up and forward until you can pull out

the seat insert.

3. The seat insert must be removed in accordance with the age specifications stated

above.

4. Restore the seat insert to its original state and fix it in place again.

By pushing the central adjustment button (z), you can adapt the safety cushion to

your child. Hold down the central adjustment button (z) while you adapt the safety

cushion to your child.

The side aps of the safety cushion (p) t exactly between the arm rests and booster

(d) and are used to support the safety cushion (p) on the seat.

Adjust the safety cushion (p) so that it rests against the child without pushing against

the child’s body.

WARNING! The safety cushion (p) may only be used in conjunction with the

frame (w) up to a maximum of 18 kg!

ADJUSTING THE SAFETY CUSHION – ECE GROUP 1 (9-18 KG)
