30
7
The scope will not turn on.
Check that the battery is installed properly. Install the battery according to
the (+) and (-) polarity, ensuring that the markings on the battery and
battery compartment correspond with one another. Check the battery
contact to ensure it is clean and free of corrosion; if necessary, clean the
contact with rubbing alcohol. Also check that the cap of the battery
department is fully closed, otherwise the device will not operate. If
necessary, replace the battery as it may be depleted. Also be sure that the
switch has been turned to the “ON” position.
Distinct black dots appear on the screen.
These dots are cosmetic blemishes resulting from tube production
processes and do not interfere with the reliability or performance of the
scope and are not a defect.
The image “snows”.
Image may “snow” in a dark environment during 30-60 seconds after the
device is activated; this effect disappears soon. Image may slightly
“snow” if the device was previously operated without the lens cap at a
high level of luminance. Image may also “snow” if the device is operated
in complete darkness with the IR illuminator off.
The image is not focused.
Adjust the focus of the eyepiece and the objective (see “Use and
Testing” section). Check that the lenses are not foggy or dusty; if they
are, carefully clean the external surfaces of lenses with a soft cotton
fabric. Replace the battery if the total battery charge is less than 2.2V.
When the unit is brought into a warm environment from a cold one,
condensation may appear on the internal lenses; you must wait two hours
before using the unit.
Visibility decreases or disappears.
Bright light sources, such as headlights, may cause visibility to decrease
or disappear and the image to flicker. Turn the power off and turn the
scope away from the light source; visibility will restore itself immediately.
If you operate the unit in a light environment without the lens cap, the
image turns dark. However if you move into a dark environment visibility
restores itself.
Pulire le lenti con detergente specifico per ottiche con trattamenti
multipli.
Togliere la polvere o lo sporco dalle lenti usando aria compressa,
secca.
Pulire il corpo dell’ con uno straccio morbido e pulito.Challenger GS
In caso di inutilizzo prolungato, rimuovere la batteria per evitare possibili
perdite. Il coperchietto del vano batteria deve essere ben chiuso in caso
di inutilizzo prolungato.
Puntare l'apparecchio acceso verso un oggetto ad una distanza di
circa 10 - 100m. Ruotare l'oculare (5), mettere a fuoco sullo schermo
del tubo - e visibile una superficie irregolare o dei piccoli punti neri.
Ruotare la lente frontale finche la qualità dell'immagine e
soddisfacente. Correggere la messa a fuoco dell'oculare, se
necessario. Dopo questa regolazione potrebbe non essere
necessario ruotare l'oculare al variare della distanza.
Puntare il Challenger GS su un oggetto e regolare la messa a fuoco
finale, ruotando la lente frontale fino ad ottenere una immagine nitida.
Ruotando la lente dell'obiettivo verso il corpo si mettono a fuoco
oggetti lontani, ruotandola in direzione opposta si mettono a fuoco
oggetti più vicini.
Dopo l'uso, riposizionare il coprilente e spegnere l'apparecchio
ruotando l'interruttore (3) verso la posizione iniziale “OFF”. Riporre
l'apparecchio nella sua custodia.
