Dell Inspiron 5567, 5567-1981 [37/108] Procedure
![Dell Inspiron 5567, 5567-9876 [37/108] Procedure](/views2/1218012/page37/bg25.png)
Replacing the coin-cell battery
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
1 Adhere the coin-cell battery to the palm rest and keyboard assembly.
2 Route the coin-cell battery cable through the routing guide on the palm
rest and keyboard assembly.
3 Connect the coin-cell battery cable to the system board.
Post-requisites
1 Replace the base cover.
2 Replace the optical drive.
37
