Replacing the hard drive

WARNING: Before working inside your computer, read the safety

information that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your

computer, follow the instructions in After working inside your

computer. For more safety best practices, see the Regulatory

Compliance home page at

www.dell.com/regulatory_compliance.

CAUTION: Hard drives are fragile. Exercise care when handling the

hard drive.

Procedure

1 Align the screw holes on the hard-drive bracket with the screw holes on

the hard drive.

2 Replace the screws that secure the hard-drive bracket to the hard drive.

3 Connect the interposer to the hard-drive assembly.

4 Align the screw holes on the hard-drive assembly with the screw holes

on the palm rest and keyboard assembly.

5 Replace the screws that secure the hard-drive assembly to the palm rest

and keyboard assembly.

6 Connect the hard-drive cable to the system board and close the latch to

secure the cable.

Post-requisites

1 Replace the I/O board.

2 Replace the base cover.

3 Replace the optical drive.
