Replacing the display panel

WARNING: Before working inside your computer, read the safety

information that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your

computer, follow the instructions in After working inside your

computer. For more safety best practices, see the Regulatory

Compliance home page at

www.dell.com/regulatory_compliance.

Procedure

1 Connect the display cable to the display-panel connector at the back of

the display panel.

2 Adhere the tape that secures the display cable to the back of the display

panel.

3 Place the display panel gently on the display back-cover.

4 Align the screw holes on the display panel with the screw holes on the

display back-cover.

5 Replace the screws that secure the display panel to the display back-

cover.

Post-requisites

1 Replace the display bezel.

2 Replace the display assembly.

3 Replace the base cover.

4 Replace the optical drive.
