Dell Inspiron 5567, 5567-1981 [48/108] Procedure

Replacing the battery

WARNING: Before working inside your computer, read the safety

information that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your

computer, follow the instructions in After working inside your

computer. For more safety best practices, see the Regulatory

Compliance home page at

www.dell.com/regulatory_compliance.

Procedure

1 Align the screw holes on the battery with the screw holes on the palm

rest and keyboard assembly.

2 Replace the screw that secures the battery to the palm rest and keyboard

assembly.

3 Align the screw holes on the battery bracket with the screw holes on the

system board and palm rest and keyboard assembly.

4 Replace the screws that secure the battery bracket to the system board

and palm rest and keyboard assembly.

Post-requisites

1 Replace the hard drive.

2 Replace the I/O board.

3 Replace the base cover.

4 Replace the optical drive.
