Dell Inspiron 5567, 5567-1981 [101/108] Replacing the power adapter port

Replacing the power-adapter

port

WARNING: Before working inside your computer, read the safety

information that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your

computer, follow the instructions in After working inside your

computer. For more safety best practices, see the Regulatory

Compliance home page at www.dell.com/regulatory_compliance.

Procedure

1 Place the power-adapter port into the slot on the palm rest and keyboard

assembly.

2 Align the screw hole on the power-adapter port with the screw hole on

the palm rest and keyboard assembly.

3 Replace the screw that secures the power-adapter port to the palm rest

and keyboard assembly.

4 Route the power-adapter port cable through the routing guides on the

palm rest and keyboard assembly.

Post-requisites

1 Replace the display panel.

2 Replace the heat-sink assembly.

3 Replace the system-board assembly.

4 Replace the wireless card.

5 Replace the memory modules.

6 Replace the status-light board.

7 Replace the battery.

8 Replace the hard drive.

9 Replace the I/O board.

10 Replace the base cover.

11 Replace the optical drive.
