Dell UltraSharp UP2718Q [10/59] Monitor specifications
![Dell UltraSharp UP2718Q [10/59] Monitor specifications](/views2/1264448/page10/bga.png)
10 | About Your Monitor
7 USB upstream ports Connect the USB cable that comes with your monitor
to the computer. Once this cable is connected, you
can use the USB downstream connectors on the
monitor.
8 USB downstream ports Connect your USB device. You can only use this
connector after you have connected the USB cable
to the computer and USB upstream connector on the
monitor. Port with battery icon supports BC 1.2.
9 Stand lock Lock the stand to the monitor using a M3 x 6 mm
screw (screw not included).
Monitor Specifications
Screen type Active matrix - TFT LCD
Panel type In-plane switching Technology
Aspect ratio 16:9
Viewable image dimensions
Diagonal 68.47 cm (27 inches)
Active Area
Horizontal 596.74 mm (23.49 inches)
Vertical 335.66 mm (13.21 inches)
Area 200301.7 mm
2
(310.47 inches
2
)
Pixel pitch 0.1554 mm x 0.1554 mm
Pixel per inch (PPI) 163
Viewing angle
Horizontal 178° (typical)
Vertical 178° (typical)
Brightness 400 cd/m² (typical)
1000 cd/m² (peak)
Contrast ratio 1000 to 1 (typical)
20,000 to 1 (peak)
Display screen coating Anti-glare treatment of the front polarizer (3H) hard coating
Backlight White LED, Direct type system
Response Time (Gray to
Gray)
6 ms (FAST mode)
8 ms (NORMAL mode)
Color depth 1.07 Billion colors
Color gamut* 100% Adobe RGB
100% sRGB
97.7% DCI-P3
76.9% REC2020
Calibration accuracy Delta E < 2 (average)
