12 | About Your Monitor
Preset Display Modes
Display Mode
Horizontal
Frequency
(kHz)
Vertical
Frequency (Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/
Vertical)
720 x 400 31.5 70.0 28.3 -/+
VESA, 640 x 480 31.5 60.0 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.0 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1600 x 1200 75.0 60.0 162.0 +/+
VESA, 1920 x 1080 67.5 60.0 148.5 +/+
VESA, 2560 x 1440-R 88.787 59.95 241.5 +/-
VESA, 3840 x 2160 65.68 30.0 262.75 +/+
VESA, 3840 x 2160 133.313 60.0 533.25 +/+
VESA, 3840 x 2160 135.0 60.0 594.0 +/+
Electrical Specifications
Video input signals •Digital video signal for each dierential line.
Per dierential line at 100 ohm impedance.
•DP/HDMI signal input support
Input voltage/ frequency/
current
100-240 VAC / 50 or 60 Hz ± 3 Hz / 1.8 A (maximum)
Inrush current 120 V: 30 A (Max.)
240 V: 60 A (Max.)
