About Your Monitor | 11
Connectivity •1 x DP 1.4 (HDCP 1.4/2.2)
•1 x mDP 1.4 (HDCP 1.4/2.2)
•2 x HDMI 2.0a (HDCP 1.4/2.2)
•2 x USB 3.0 downstream port
•2 x USB 3.0 with BC1.2 charging capability at 2A (max)
•2 x USB 3.0 upstream port
•1 x Analog audio line out (3.5mm jack)
Border width (edge of
monitor to active area)
13.79 mm (Top/Left/Right)
17.59 mm (Bottom)
Adjustability
Height adjustable stand 145 mm
Tilt -5° to 21°
Swivel -45° to 45°
Pivot 0° to 90°
Cable management Yes
Dell Display Manager
(DDM) Compatibility
Easy Arrange and other key features
Security Security lock slot (cable lock sold separately) Anti-theft
stand lock slot (to panel)
NOTE *: at panel native only, under Custom Mode preset.
Resolution Specifications
Horizontal scan range
30 kHz to 140 kHz (DP/HDMI)
Vertical scan range 24 Hz to 75 Hz (DP/HDMI)
Maximum preset resolution 3840 x 2160 at 60 Hz
Video display capabilities
(DP & HDMI playback)
480p, 576p, 720p, 1080i, 1080p, UHD
