Operating your Monitor | 17
4
Exit
Use this button to go back to the main menu or
exit the OSD main menu.
5
Power On/Off button (with
LED indicator)
Use the Power button to turn the monitor On
and Off.
Solid white light indicates the monitor is On and
fully functional. Blinking white light indicates the
power save mode.
OSD controls
Use the buttons on the front of the monitor to adjust the image settings.
1
2
3
4
Front Panel Button Description
1
Up
Use the Up button to increase values or move up.
2
Down
Use the Down button to adjust (decrease ranges)
items in the OSD menu.
3
OK
Use the OK button to confirm your selection.
4
Back
Use the Back button to go back to the previous menu.
