![Dell S2318M [42/47] Physical characteristics](/views2/1264515/page42/bg2a.png)
42 | Monitor Specifications
Physical Characteristics
Model S2218M S2318M
Signal cable type
∞
Digital: detachable, DVI,
Solid pins.
∞
Analog: detachable,
D-Sub, 15 pins
∞
Digital: detachable, DVI,
Solid pins.
∞
Analog: detachable,
D-Sub, 15 pins
Dimensions (with stand)
Height 385.5 mm (15.18 in) 404.0 mm (15.90 in)
Width 489.5 mm (19.27 in) 522.2 mm (20.56 in)
Depth 147.9 mm (5.82 in) 147.9 mm (5.82 in)
Dimensions (without stand)
Height 293.9 mm (11.57 in) 312.3 mm (12.29 in)
Width 489.5 mm (19.27 in) 522.2 mm (20.56 in)
Depth 49.1 mm (1.93 in) 49.1 mm (1.93 in)
Stand dimensions
Height 171.6 mm (6.76 in) 171.6 mm (6.76 in)
Width 246.6 mm (9.71 in) 246.6 mm (9.71 in)
Depth 147.9 mm (5.82 in) 147.9 mm (5.82 in)
Weight
Weight with packaging 4.93 kg (10.87 lb) 5.34 kg (11.78 lb)
Weight with stand
assembly and cables
3.26 kg (7.19 lb) 3.57 kg (7.88 lb)
Weight without stand
assembly
2.27 kg (5.00 lb) 2.58 kg (5.69 lb)
Weight of stand
assembly
0.53 kg (1.17 lb) 0.53 kg (1.17 lb)
Front frame gloss Black frame - 85 gloss unit
(minimum)
Black frame - 85 gloss unit
(minimum)
