Operating your Monitor | 29
When the monitor enters the Power Save Mode, the following message appears:
Dell S2X18M
Entering Power Save Mode.
If you press any button other than the power button, the following messages will
appear depending on the selected input:
Dell S2X18M
There is no signal coming from your computer. Press any key on the
keyboard or move the mouse to wake it up. If there is no display, press
the monitor button now to select the correct input source on the
On-Screen-Display menu.
If VGA or DVI cable is not connected, a floating dialog box as shown below appears.
The monitor will enter Power Save Mode after 4 minutes if left at this state.
Dell S2X18M
No VGA Cable
The display will go into Power Save Mode in 4 minutes.
www.dell.com/support/monitors
?
Dell S2X18M
The display will go into Power Save Mode in 4 minutes.
www.dell.com/support/monitors
No DVI Cable
?
See Troubleshooting for more information.
