Introduction

Congratulations and thank you for purchasing a Fractal Design computer case.

Please thoroughly read the following information and instructions before using your new case.

Arc Mini R2

The Arc Mini R2 micro ATX case combines excellent cooling potential and build congurabil-

ity in a compact, minimalistic and elegant chassis design.

The Arc series of cases is dedicated to delivering optimized cooling solutions and the Arc

Mini R2 is no exception. The adaptable hard drive cage design brings forth options for mul-

tiple cooling setups. For a case of this size, it offers unmatched possibilities for water cooling

components with a choice to even t a 360mm thick radiator in the roof. The three Silent

Series R2 fans included in the case contribute to excellent cooling straight out of the box.

The Arc Mini R2 is compact but the size does not compromise exibility for component con-

guration and drive capacity. With room for up to six 3.5” drives plus an additional two 2.5”

drives hidden behind the motherboard plate, you can build a well-cooled PC with ample stor-

age space.

As in all our products, the Arc Mini R2 highlights ease of use alongside quality workmanship

and materials, which is something Fractal Design takes pride in. The case is built to last and

is lled with smart features such dust lters, integrated fan controller and plenty of space for

tidy cable routing. To top it all off, the Arc Mini R2 comes with a beautiful, slightly tinted win-

dow side panel which allows you to show off your build from the outside.

Fan controller

To install the built-in fan controller you have four con-

nectors, three of which you connect to your case fans

and one Molex connector which you plug into your

power supply unit. The speed of the fans can be regu-

lated in three steps, low speed (5V), medium speed

(7V) and high speed (12V).

Note: Some fans might not start in the low-speed position

and require a higher setting. Check the Starting Voltage of

non-Fractal Design fans for which setting should be used.

Cleaning the dust lters

The Arc Mini R2 comes with 3 separate dust lters:

• Front panel: Remove the front dust lter by pushing the upper part of the mesh; the

lter can be cleaned under running water or

by using a vacuum cleaner.

• Bottom lter: The lter located under the

power supply is removable by pulling it

straight out at the back of the case; it can be

cleaned under running water.

• Top panel: This lter is easiest to clean by

just using a vacuum cleaner, but can also be

taken off by removing the two thumbscrews at

the rear of the case.
