1-2 ProductSpecications
CPU Support for Intel
®
Core
™
X series processors in the LGA2066 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset
Intel
®
X299 Express Chipset
Memory 8xDDR4DIMMsocketssupportingupto128GBofsystemmemory
(Note 1)
* Supportforupto512GBofsystemmemorywhenusingRegisteredDIMMs.
4xDDR4DIMMsocketssupportingupto64GBofsystemmemory
(Note 2)
4 channel memory architecture
(Note 1)
Dual channel memory architecture
(Note 2)
SupportforDDR42667/2400/2133MHzmemorymodules
Support for non-ECC Un-buffered DIMM memory modules
SupportforRegisteredDIMM1Rx8/2Rx8/1Rx4/2Rx4memorymodules(operate
in non-ECC mode)
SupportforExtremeMemoryProle(XMP)memorymodules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Realtek
®
ALC1220 codec
HighDenitionAudio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Intel
®
GbE LAN chip (10/100/1000 Mbit)
Expansion Slots 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
1 x PCI Express x16 slot, running at x8 (PCIEX8)
2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
* Referto"1-6 Setting upAMDCrossFire
™
/NVIDIA
®
SLI
™
Conguration,"for the
installation notices for the PCI Express x16 slots.
Multi-Graphics
Technology
Support for NVIDIA
®
Quad-GPU SLI
™
and 3-Way
(Note 3)
/2-Way
(Note 1)
NVIDIA
®
SLI
™
technologies
Support for AMD Quad-GPU CrossFire
™
and 3-Way
(Note 3)
/2-Way AMD CrossFire
™
technologies
Storage Interface Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe
x4/x2 SSD support) (M2Q_32G)
- 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe
x4/x2 SSD support) (M2P_32G)
- 8 x SATA 6Gb/s connectors
- SupportforRAID0,RAID1,RAID5,andRAID10
* Referto"1-9InternalConnectors,"fortheinstallationnoticesfortheM.2andSATA
connectors.
(Note 1) Supported when using a 44-lane or 28-lane CPU.
(Note 2) Supported when using a 16-lane CPU.
(Note 3) Supported when using a 44-lane CPU.
- 6 -
