14 15
SE 3.6 LA 036
............................... 3 mm
............................... 6 mm
............................ 4,5 mm
........................... 200 min
-1
........................... 600 min
-1
............................ 4,5 Nm
............................ 6,5 Nm
............................... 140
............................ 3,6 V
........................ 0,575 kg
............................. 56 dB (A)
............................ 2,8 m/s
2
............................ 1,5 m/s
2
......................... < 2,5 m/s
2
............................ 1,3 m/s
2
................................. .................................. 3,6 V
................................. .................................. 1,8 A
................................. ............................50-100 mA
................................. ............................. ca. 45 min
................................. ............................. ca. 65 min
................................. ............................. ca. 60 min
................................. ................................. 285 g
This charger is not intended for use by young children or inrm
persons without supervision. Young children should be
supervised to ensure that they do not play with the charger.
This tool is not intended for use by persons (including children)
with limited physical, sensory or mental capabilities or insufcient
experience and/or knowledge unless they are supervised by a
person who is responsible for their safety or have been
instructed by them in the safe use of the tool.
Children should be supervised in order to ensure that they do not
play with the tool.
SPECIFIED CONDITIONS OF USE
The battery drill/screwdriver is designed for drilling and
screwdriving for independent use away from mains supply.
The quick charger can charge AEG batteries System SE36 from
3,6 V.
Do not use this product in any other way as stated for normal
use.
MAINS CONNECTION LA 036
Connect only to single-phase a.c. current and only to the system
voltage indicated on the rating plate. It is also possible to
connect to sockets without an earthing contact as the design
conforms to safety class II.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product is in
conformity with the following standards or standardized
documents: EN 60745, EN 55014-1, EN 55014-2, EN 60335,
EN 61000-3-2, EN 61000-3-3, EN 50366 in accordance with the
regulations 98/37/EC, 2006/95/EC, 2004/108/EC
Rainer Kumpf
Manager Product Development
Winnenden, 2009-05-19
ADVICE FOR OPERATION
Never use the gear switch whilst the machine is operating. Only
use the switch when the machine is at a standstill.
BATTERIES
New battery packs reach full loading capacity after 4 - 5
chargings and dischargings. Battery packs which have not been
used for some time should be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance
of the battery pack. Avoid extended exposure to heat or sunshine
(risk of overheating).
The contacts of chargers and battery packs must be kept clean.
General note concerning NiMH batteries: The capacity of the
battery is reduced when the temperature falls below -10°C.
Long-term storage at temperatures higher than +40°C may have
negative effects on the capacity of the battery.
CHARACTERISTICS
After inserting the battery into the reception of the charger the
battery will automatically be charged (yellow control lamp is
illuminated continuously)
When a hot or cold battery pack is inserted into the charger
(ashing red lamp), charging will begin automatically once the
battery reaches the correct charging temperature (NiCd/NiMh
-5°C...50°C, Li-Ion 0°C...55°C).
Charging time varies depending on the battery temperature,
charge needed and the type of battery pack being charged.
As soon as charging is completed, the charger switches over to
”trickle” charge to maintain the full capacity (green control lamp
is illuminated continuously)
It is not necessary to remove the battery after charging. The
battery can be stored permanently in the charger without the
danger of being overcharged.
If both LEDs ash, either the battery has not been completely
mounted or there is a fault in the battery or the charger. For
safety reasons you must stop using the charger and battery
immediately and have them inspected by an AEG Customer
Service Centre.
MAINTENANCE
If the supply cord of this appliance is damaged, it must only be
replaced by a repair shop appointed by the manufacturer,
because special parts are required
Use only AEG accessories and spare parts. Should components
need to be replaced which have not been described, please
contact one of our AEG service agents (see our list of guarantee/
service addresses).
If needed, an exploded view of the tool can be ordered. Please
state the Article No. as well as the machine type printed on the
label and order the drawing at your local service agents or
directly at: AEG Elektrowerkzeuge, Max-Eyth-Straße 10,
D-71364 Winnenden, Germany.
SYMBOLS
Please read the instructions carefully
before starting the machine.
Accessory - Not included in standard equipment,
available as an accessory.
Remove the battery pack before starting any work
on the machine.
Do not dispose of electric tools together with
household waste material! In observance of
European Directive 2002/96/EC on waste electrical
and electronic equipment and its implementation in
accordance with national law, electric tools that
have reached the end of their life must be collected
separately and returned to an environmentally
compatible recycling facility.
Do not burn used battery packs.
Never charge a damaged battery pack. Replace by
a new one.
ENGLISHENGLISH
TECHNICAL DATA
Drilling capacity in steel ..................................................................
Drilling capacity in wood .................................................................
Wood screws (without pre-drilling) .................................................
No-load speed, 1st gear .................................................................
No-load speed, 2nd gear ................................................................
Torque
Low torque *1 ..............................................................................
High torque *1 .............................................................................
Screwing capacity with one fully charged battery (2.0 Ah): *2
4x30 Soft wood ............................................................................
Battery voltage................................................................................
Weight with battery .........................................................................
Noise/vibration information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K = 3 dB(A)) ..............................................
The noise level when working can exceed 85 dB (A).
Wear ear protectors!
Total vibration values (vector sum in the three axes) determined
according to EN 60745.
Vibration emission value ah
Drilling into metal .........................................................................
Uncertainty K ...............................................................................
Screwing ......................................................................................
Uncertainty K ...............................................................................
Voltage range .................................................................................
Quick charge current NiCd / NiMH / Li-Ion .....................................
Maintaining charge .........................................................................
Battery charging time NiCd 1,4 Ah .................................................
Battery charging time NiMH 2,0 Ah ................................................
Battery charging time Li-Ion 1,5 Ah ................................................
Weight without cable ......................................................................
WARNING! Read all safety warnings and all instructions,
including those given in the accompanying brochure. Failure
to follow the warnings and instructions may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory may
contact hidden wiring or its own cord. Contact with a „live“
wire will also make exposed metal parts of the power tool „live“
and shock the operator.
Wear ear protectors. Exposure to noise can cause hearing loss.
Always wear goggles when using the machine. It is
recommended to wear gloves, sturdy non slipping shoes and
apron.
Sawdust and splinters must not be removed while the machine is
running.
When working in walls ceiling, or oor, take care to avoid electric
cables and gas or waterpipes.
Remove the battery pack before starting any work on the
machine.
Do not dispose of used battery packs in the household refuse or
by burning them. AEG Distributors offer to retrieve old batteries
to protect our environment.
Do not store the battery pack together with metal objects (short
circuit risk).
Use only System SE36 chargers for charging System SE36
battery packs. Do not use battery packs from other systems.
Battery acid may leak from damaged batteries under extreme
load or extreme temperatures. In case of contact with battery
acid wash it off immediately with soap and water. In case of eye
contact rinse thoroughly for at least 10 minutes and immediately
seek medical attention.
The following battery packs can be charged with this charger:
voltage battery rating No. of
(of storage battery) battery
cells
3.6 V SB 3.6 1.4 Ah 3
3.6 V SM 3.6 2.0 Ah 3
3.6 V SL 3,6 1.5 Ah 1
Do not try to charge non-chargeable batteries with this charger.
No metal parts must be allowed to enter the battery section of
the charger (short circuit risk).
Never break open battery packs and chargers and store only in
dry rooms. Keep dry at all times.
Do not touch the tool with conducting objects.
Never charge a damaged battery pack. Replace by a new one.
Before use check machine, cable, and plug for any damages or
material fatigue. Repairs should only be carried out by
authorised Service Agents.
*1 Measured according to AEG norm N 877318
*2 The values stated are reference values (2nd gear). Actual values might differ, depending on the material and quality of the screws.
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different applications,
with different accessories or poorly maintained, the vibration emission may differ. This may signicantly increase the exposure level over
the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it is
running but not actually doing the job. This may signicantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the accessories,
keep the hands warm, organisation of work patterns.
