![Panasonic NN-GT260 [11/109] Parts of your oven](/img/pdf.png)
Panasonic NN-GT260 [11/109] Parts of your oven
![Panasonic NN-GM230 [11/109] Parts of your oven](/views2/1027665/page11/bgb.png)
1. Do not operate the oven without the Roller
Ring and Glass Turntable in place.
2. Only use the Glass Turntable specifically
designed for this oven. Do not substitute
with any other Glass Turntable.
3. If Glass Turntable is hot, allow to cool
before cleaning or placing in water.
4. Do not cook directly on Glass Turntable.
Always place food in a microwave safe
dish. The only exception to this is when
cooking Jacket Potatoes or Auto Program
Jacket Potatoes.
5. If food or utensils on the glass turntable
touch the oven walls, this will cause the
turntable to stop moving, it will then
automatically rotate in the opposite
direction. This is normal. Open oven door,
reposition the food and restart.
6. The Glass Turntable can rotate in either
direction. The maximum weight that can
be placed on the turntable is 3 Kg (6 lb 10
oz) (this includes total weight of food and
dish).
7. While cooking by MICROWAVE or
COMBINATION the turntable may vibrate.
This will not affect cooking performance.
8.
as directed for GRILLING and
COMBINATION cooking. Never use this
on MICROWAVE only. Do not use if
operating the oven with less than 200g
(7oz) of food on a manual Combination
program. FAILURE TO USE
ACCESSORIES CORRECTLY COULD
DAMAGE YOUR OVEN.
9. Arcing may occur if the incorrect weight of
food is used, a metal container has been
used accidentally, or the grill rack has
been damaged. If this occurs, stop the
machine immediately. You can continue to
cook by GRILL ONLY.
10. Always refer to instructions for correct
accessories to use on all programs. The
glass turntable and Roller Ring are the
only accessories used for MICROWAVE
cooking.
Parts of Your Oven
Glass Turntable
The glass turntable and roller ring are the only
accessories used for Microwave Cooking.
Door Safety
Lock System
Control Panel
Roller Ring
1. The Roller Ring and oven
floor should be cleaned
frequently to prevent
excessive noise.
2. The Roller Ring must always
be used together with the
Glass Turntable for cooking.
Door Safety
Lock System
Microwave
Feed Guide
(Do not remove)
Grill Element
See-through
Oven Window
External Air Vents
Door Release Pad
Push to open the door.
Opening the door during cooking will stop the
cooking process without cancelling the
Display Window
Identification Plate
Power Supply Cord
(Not for NN-GM230)
program.
For NN-GT260
Cooking resumes as soon as the door is closed
and start is pressed.
For NN-GM230
Cooking continues as soon as the door is closed.
The metal Wire Rack must ONLY be used
Wire Rack
English
En-9
