Pilotage Автомодель Monster ONE RTR 4WD 1/10 (RC16588) [23/48] Camber adjustment

21

Changing Shock Oil

The shocks in this model are lled with silicone oil. Using oils of various viscosities will adjust the performance

of this model. Thinner oil enhances performance on at or rough surfaces, while thick oil improves jumping

performance and provides better handling on hilly o road surfaces.

Changing the Pinion Gear

Pilotage oers a number of dierent pinion gears for your electric motor. Switching the pinion gear changes the

gear ratio with the spur gear. When using a pinion gear with a lower number of teeth, acceleration is improved

but the top speed will be reduced. When using a pinion gear with a greater number of teeth you will be able to

of the model. After adjusting the turnbuckle lock, be sure to lock it into place using threadlocker.

This is an example of negative camber. This is when the top

of the wheel is closer to the centre of the car compared to the

bottom of the wheel. Negative camber will give more contact

area while cornering and more grip. Excessive amounts of

camber will cause less grip and uneven wear to the tires.

This is an example of positive camber. This is when the bottom

of the wheel is closer to the centre of the car compared to the

top of the wheel. Positive camber will give less contact area in

the corner and less grip. Excessive amounts will cause less grip

and uneven wear.

Front / rear

Upper linkage set

Front / rear

Upper linkage set

Positive

camber

Negative

camber
