Windows Utilities
-119-
Useful Software
7
3 Click [Run setup.exe].
If the [User Account Control] dialog box
appears, click [Yes].
4 Select language and click [Next].
5 Select the model and click [OK].
6 Read the user license agreement and
click [I Agree].
7 Select [Device Configuration].
8 Click [Change the Printer Display
Language].
9 Check [Country Code] and click [Next].
10 Click on [Next].
11 Select the model name of the machine
and click on [Next].
12
Select the country code and click on [
Next
].
13 Click on [Setup].
Setup the date and time (MB451/
MB451w/MB471/MB471w/MB491/
ES4191 MPF only)
1 Hold down the power switch for about a
second to turn on the power.
2 Plug in the computer, and insert the
Software DVD-ROM.
3 Click [Run setup.exe].
If the [User Account Control] dialog box
appears, click [Yes].
4 Select language and click [Next].
5 Select the model and click [OK].
6 Read the user license agreement and
click [I Agree].
7 Select [Device Configuration].
8 Click [Change the Printer Display
Language].
9
Check [
Date and Time
] and click [
Next
].
10 Click on [Next].
11 Select the model name of the machine
and click on [Next].
12
Set the date and time and click on [
Next
].
13 Click on [Setup].
Network Card Setup
You can use the Network Card Setup to configure
the network.
In order to use Network Card Setup, TCP/IP
needs to be activated.
Note
This requires administrator rights.
Even when connected using a wireless LAN, the displayed
MAC address becomes the MAC address of the wired LAN.
Memo
To check the machine MAC address, press the <SETTINGS>
key, and on the machine operating panel select [View
Information]>[Network].
Launching the Utility
1 Hold down the power switch for about a
second to turn on the power.
2 Turn on you computer, and insert the
Software DVD-ROM.
3 Click [Run setup.exe].
If the [User Account Control] dialog box
appears, click [Yes].
4 Select the device and click [Next].
5 Read the user license agreement and
click on [I Agree].
6 Select [Device Configuration]>
[Network Card Setup Utility].
Configuring Network Settings
1 Launch Network Card Setup.
2 Select the machine from a list.
3 Select [Setting Printer] from the
[Setting] menu.
4 Change the items as required and click
on [OK].
