List of the Device Setting Menu Items
-95-
Configuring at the Operator Panel
6
Network Scale Normal When [Normal] is set: the machine works
effectively even when connected to a HUB
that has a spanning tree feature. However,
printer start up time gets longer when
computers are connected to two or three
small LANs.
When [
Small
] is set: computers can cover
from two or three small LANs to a largeLAN,
but it may not work effectively when it is con-
nected to a HUB with a spanning tree feature.
HUB Link Setting Auto Negoti-
ate
Sets the hub linking method. Usually,
select [Auto Negotiate].
TCP ACK Type1 Sets a type of TCP Acknowledgment.
When Type1 is set, the printer replies to
every packet.
When Type2 is set, the printer replies to
plural packets in a mass.
When printing comes to take time by the
setting of the hub, choosing Type2 may
improve the matter.
Usually, setting Type1 hasn't any problem.
Network PS-Protocol (MB451/MB451w/
MB471/MB471w/MB491/ES4191 MFP Only)
RAW Sets a PS-protocol.
Wireless
Setting
Manual
Setup
SSID default Input SSID
Security Disable The security of the wireless LAN function
WPA-EAP can set only in Web.
WEP Key (NULL) Input WEP Key
This item is displayed when WEP was
selected in the Security item.
WPA Encryp-
tion Type
TKIP WPA-PSK coding method
This item is displayed when WPA or WPA2
was selected in the Security item.
WPA Pre-
shared Key
(NULL) Input Pre Shared Key
This item is displayed when WPA or WPA2
was selected in the Security item.
Set automat-
ically (WPS)
WPS-PBC - WPS-PBC is executed.
WPS-PIN - WPS-PIN is executed.
Wireless
reconnection
- Wireless reconnection is executed.
Enabling Wired
Communications
- Wired environment is validated.
This item is displayed when Wireless LAN
is effective.
Factory
Defaults
Execute
The settings of the network, mail server, LDAP
server, and secure protocol server are returned
to the default settings.
Mail
Server
Setup
SMTP Server (NULL) Sets the IP address or host name for the
SMTP server.
SMTP Port 25
Sets the port number. Usually, the default is used.
Available range: 1 to 65535
SMTP Encryption None Selects an encryption method in the SMTP
communication.
Receive Setting Disable Select a protocol to use for the E-mail
reception.
POP3 Server (NULL) Sets the IP address or host name for the
POP3 server.
POP3 Port 110 Sets the port number prepared by the
POP3 on the POP3 server.
Available range: 1 to 65535.
Item
Factory
Default
Description
