OKI MB471 [91/176] Configuring at the operator panel
![OKI MB471 [91/176] Configuring at the operator panel](/views2/1029568/page91/bg5b.png)
List of the Device Setting Menu Items
-91-
Configuring at the Operator Panel
6
Print Position
Adjust
Front X Adjust 0.00 mm Adjusts the position of the whole printing
image perpendicular to the direction of
paper movement. Available range: ±2.00
mm (0.25 increments).
Front Y Adjust 0.00 mm Adjusts the position of the whole printing
image parallel to the direction of paper
movement. Available range:
±2.00 mm
(0.25 increments).
Back X Adjust 0.00 mm Adjusts the position of the image on the
reverse side of a duplex print perpendicu-
lar to the direction of paper movement.
Available range: ±2.00 mm (0.25 incre-
ments).
Back Y Adjust 0.00 mm Adjusts the position of the image on the
reverse size of a duplex print parallel to
the direction of paper movement. Avail-
able range: ±2.00 mm (0.25 increments).
Drum Cleaning OFF Sets whether to do cleaning of a drum
before printing. It may have an effect for
improvement of image quality.
Hex Dump OFF Prints out the data received from the host
computer in hexidecimal code. To finish
printing, turn off the power.
System
Configu-
ration
Menu
Personality Auto Emula-
tion
Selects the emulation mode. When set to
auto, the correct emulation is automatically
selected each time a print job is received.
Alarm Release Manual When [Manual] is selected, non-critical
warnings, such as requests for a different
paper size, can be cleared by pressing the
<RESET/LOG OUT> key. When [Auto] is
selected, they are cleared when the print
job resumes.
Auto Continue OFF Sets whether the machine automatically
recovers from a memory overflow.
Error Report OFF Sets whether to print error details when
PostScript errors occur.
PCL
Setup
Font Source Resident Selects the location of the font to use.
Font No. I0 Selects the number of the font to use.
Available range: I0 to I90 when [Resi-
dent] is set.
Font Pitch 10.00 CPI Sets the width of the PCL default font.
Available range: 0.44 to 99.99 CPI
(0.01CPI increments).
Font Height 12.00 point Sets the height of the PCL default font.
Available range: 4.00 to 999.75 point.
(0.25 point increments)
Symbol Set PC-8 Selects a PCL symbol set.
A4 Print Width 78 Column Sets a number of digits for automatic line
feed on A4 paper.
White Page Skip OFF Selects whether to print blank pages.
CR Function CR Sets the machine operation when receiv-
ing CR code.
LF Function LF Sets the machine operation when
receiving LF code.
Item
Factory
Default
Description
