OKI MB471 [79/176] Network scan destination
![OKI MB471 [79/176] Network scan destination](/views2/1029568/page79/bg4f.png)
List of the Device Setting Menu Items
-79-
Configuring at the Operator Panel
6
*1 In profiles, "#n" or #d" can be specified for [File Name].
When specifying "#n": 5-digit serial number between 00000 to 99999
When specifying "#d": Date and time when a file is created. 12 digits of yymmddhhmmss.
Example of file name specification (when the file format is PDF)
Note
File names registered in profiles, are applied when executing Scan To Network PC.
When performing Auto Deliver using profiles with these file names, the above names are not applied.
The file name at Auto Delive is fixed to "yymmddhhmmss_xxxxxxxx.pdf". The part of "yymmddhhmmss" is date and time when
a file is created for the above "#d", and the part of "_xxxxxxxx" is additional 8 numeric values (meaningless value) so as not to
duplicate other files.
Network Scan Destination
Store Document Settings
yy: Year created (the last 2 digits of
the Christian Era)
hh: Hours created (00 to 23)
mm: Month created (01 to 12) mm: Minute created (00 to 59)
dd: Date created (01 to 31) ss: Second created (00 to 59)
*A date and time when a file is created are values of the timer of MB491.
When specifying "Data#n": Saved as file names such as "Data0000.pdf" and
"Data00001.pdf",etc.
When specifying "File#d": saved as file names "File090715185045.pdf", etc.
When specifying "Scan": "Scan.pdf" is created first, and then, data is saved with the name
of"Scan#d.pdf".
For "#d", refer to the above.
When nothing is specified: "Image.pdf" is created first and then, data is saved with the name of
"Image#d.pdf".
For "#d", refer to the above.
Item
Factory
Default
Description
Edit/
Register
Destination (NULL) Sets a destination name. Maximum 16
characters.
Destination Address (NULL) Sets a destination address. Maximum 64
characters.
Port No. 9968 Sets a port number.
Available range: 1 to 65535.
Delete Deletes a destination.
Sort By Name Sorts destinations by name.
Sort By Number Sorts destinations into registered numeri-
cal order.
Search Searches for network scan destination by
entering head of the name.
Item Description
Store Fcode Bulletin
board
Over Write Stores documents in a bulletin box.
Delete Fcode Bulletin Board Deletes accumulated documents.
Print Fcode Box Prints accumulated document in Fcode
Confidential Box.
Received Documents Prints accumulated documents in memory.
