Changing Network Settings From the Web Page
-153-
Network Settings
8
13 On the [Key Exchange Security
Methods] window, click [Add].
14 Specify [Integrity algorithm],
[Encryption algorithm], and [Diffie-
Hellman group].
Note
Select the same value that was specified in [IKE
Encryption Algorithm], [IKE Hush Algorithm],
and [Diffie-Hellman group] at the time of
configuration for "Phase1 Proposal" in "Configuring
Your Machine" P. 152.
15 Click [OK].
16 On the [Key Exchange Security
Methods] window, click [OK].
17 On the [Key Exchange Settings]
window, click [OK].
18 On the IP security policy properties
window, select the [Rules] tab.
19 Click [Add].
20 On the [Security Rule Wizard], click
[Next].
21 On the [Tunnel Endpoint] screen,
select [This rule does not specify a
tunnel and then click [Next].
22 On the [Network Type] screen, select
[All Network Connections] and then
click [Next].
23 On the [IP Filter List] screen, click
[Add].
24 On the [IP Filter List] window, click
[Add].
25 On the [IP Filter Wizard], click [Next].
26 On the [IP Filter Description and
Mirrored Property] screen, click
[Next].
27 On the [IP Traffic Source] screen, click
[Next].
28 On the [IP Traffic Destination] screen,
click [Next].
29 On the [IP Protocol Type] screen, click
[Next].
30 Click [Finish].
31 On the [IP Filter List] window, click
[OK].
32 On the [Security Rule Wizard], select
the new IP filter from the list and then
click [Next].
33 On the [Filter Action] screen, click
[Add].
34 On the [Filter Action Wizard], click
[Next].
35 On the [Filter Action Name] screen,
enter a [Name] and a [Description]
and then click [Next].
36 On the [Filter Action General Options]
screen, select [Negotiate security] and
then click [Next].
37 On the [Communicating with
computers that do not support
IPsec] screen, select [Do not allow
unsecured communication] and then
click [Next].
38 On the [IP Traffic Security] screen,
select[Custom] and then click
[Settings].
39 On the [Custom Security Method
Settings] window, configure the settings
and then click [OK].
Note
Configure the AH and ESP settings to the same
settings as configured for the "Phase2 Proposal" in
"Configuring Your Machine" P. 152.
40 On the [IP Traffic Security] screen,
click [Next].
41 Select [Edit Properties] and then click
[Finish].
42 On the filter action properties window,
select [Use session key perfect
forward secrecy (PFS)] if you want to
enable Key PFS.
43 Select [Accept unsecured
communication, but always respond
using IPsec] if you perform IPSec
communication by the IPv6 global
address.
44 Click [OK].
45 Select the new filter action and then click
[Next].
46 On the [Authentication Method]
screen, select the authentication method
you want and then click [Next].
