Getting Started
9
Getting Started
5 Press PROGRAM +/– (repeatedly) to select the correct TV
system.
If you watch the system B/G, select “G”. If you watch the
system D/K, select “K”.
6 Tune the TV to the same channel as that
shown in the display window so that
the picture on the right appears on the
TV screen.
Refer to your TV manual for tuning
instructions.
If the picture does not appear clearly,
see “To obtain a clear picture from the
VCR” below.
7 Press RF CHANNEL.
You have now tuned your TV to the VCR. Whenever you want
to play a tape, set the TV to the video channel.
To check to see if the TV tuning is correct
Set the TV to the video channel and press PROGRAM +/– on the VCR. If
the TV screen changes to a different programme each time you press
PROGRAM +/–, the TV tuning is correct.
To obtain a clear picture from the VCR
If the picture does not appear clearly in step 6 above, go to step 7 to finish
this procedure once. Then start from step 2. After pressing RF
CHANNEL in step 2 to display the RF channel, press PROGRAM +/– so
that another RF channel appears. Then tune the TV to the new RF
channel until a clear picture appears.
Note
• If you set the wrong TV system, you may have no sound or sound may be
distorted.
SONY VIDEO CASSETTE
RECORDER
RF CHANNEL
AUTO SET UP
PROG
