Additional Operations 35
Editing with another VCR
How to connect to record on this VCR
LINE-1 IN
TV
Other VCR (Player)
LINE OUT
VMC-710M/720M audio/video cable (not supplied)
: Signal flow
Other VCR (Player)
LINE-2 IN
LINE OUT
VMC-710M/720M audio/video cable (not supplied)
: Signal flow
This VCR (Recorder)
This VCR (Recorder)
You can also connect to the jacks on the front panel (SLV-E380EE only).
Notes
• Make sure you connect the plugs to jacks of the same colour.
• If you connect this VCR to both the LINE IN and LINE OUT jacks of the other VCR,
select the input correctly to prevent a humming noise.
continued
