Getting Started
10
Step 5
Setting up the
VCR with the
Auto Set Up
function
Before using the VCR for the first time,
set up the VCR using the Auto Set Up
function. With this function, you can set
TV channels, guided by the sequence
indicated in the display window.
Hold down AUTO SET UP on the VCR for
more than three seconds.
The VCR automatically turns
on. The ATP (Auto Tuner
Preset) function starts search-
ing for all of the receivable
channels and presets them in
numerical order.
When no more receivable
channels can be found,
presetting stops and “SET UP”
disappears from the display
window.
AUTO SET UP
RF CHANNEL
AUTO SET UP
