User

Manual

Zenith Relax

Содержание

Caution 1
Hx_zenith_relax_carrier_bow_us_um_cover_2016 01 07 1
Ok not ok 1
User manual 1
Zenith relax 1
Main seat 2 restraint system 3 belt lock 4 foot rests 5 carrier bow 6 fastening bracket complete a bracket b metal strips c fastening screws d safety indicator 7 locking pin 8 reclining knob 9 footguard 2
Zenith relax 2
Hx_zenith_relax_carrier_bow_us_um_spreads_2016 01 07 3
Manuel de l utilisateur fr 3
Manual del usuario es 4
Press the front of the mounting bracket 6 to release the bracket from the transportation pins 13 remove the transportation pins the transportation pins 13 are recyclable 6
Remove cable tie protective foam blocks 6
Remove the cable tie 11 by clipping them then remove the protection foam blocks 12 from the front and back both the cable tie and protection foam blocks are recyclable 6
Remove the transportation lock 6
Zenith relax 6
Insert the carrier bow 5 through the holes as shown below 7
Mount the carrier bar to the seat 7
Remove locking pin 7
Turn the seat 1 upside down turn the locking pin 7 and push down the two snapfits before you pull the locking pin completely out 7
Zenith relax 7
Fastening bracket 8
If there is a gear wire in the area where the metal strips 6b will be located the metal strips 6b may be placed between the wire and the frame tube 8
Insert locking pin 8
Insert the locking pin 7 through the holes under the seat base keeping it in unlocked position to allow final adjustment later on 8
Locked 2 unlocked 8
Place the fastening bracket 6a over the frame tube of the bike attach the bracket with the metal strips fastening screws 6b c do not tighten fully so that the height can be adjusted at a later stage 8
Zenith relax 8
Adjust the bracket 6a to the correct height until there is approx 10 12 cm between the rear wheel mudguard luggage carrier and the bicycle child seat 9
Guide the carrier bow ends 5 down into the bracket 6a until you hear a click locked position 9
Hamax fastening bracket 9
Hamax fastening bracket make sure the carrier bow is correctly attached to the bracket by checking that the green safety indicators 7d are visible 9
Make it a rule to check and if needed re tighten the bracket before every bicycle ride 9
Mount the bicycle child seat onto the bracket 9
Not fastened fastened 9
Suggested tightening torque is 10 nm this is however only a guideline if the bracket starts to move during use keep tightening until it is firmly fixed 9
Then tighten the four fastening screws 6c on the back of the bracket in the following pattern tighten and then re tighten 9
Zenith relax 9
Adjusting the seat 10
Foot rest adjustment 10
How to release the foot rest 4 release the footrest handle on the back by flipping it upwards move the foot rest 4 to the preferred height and fasten the foot rest by pressing the foot rest handle down 10
Locked 10
Make sure the locking pin 7 is in the unlocked position before adjusting the seat to the correct lengthways position max 10 cm between the centre mark 14 on the seat and the rear hub after adjustment lock the seat by turning the locking pin 7 to locked position 10
Unlocked 10
Zenith relax 10
Extra footguard 11
Foot strap adjustment 11
How to fasten release the foot strap a to fasten the foot strap put the strap into the track and pull down to preferred length the strap will automatically lock it s only possible to tighten the strap when it is in the track to loosen the foot strap just pull it out of the track 11
Opposite view 11
To mount the extra foot guard 9 press the foot guard into the fitting grooves until it clicks 11
Zenith relax 11
Chest buckle adjustment 12
Pic 2 pic 3 12
Restraint system 12
The restraint system 2 can be attached and detached by pressing in or out the belt lock 3 shown in pic 1 it is important to press at the middle of the belt lock button pic 2 3 when detaching the restraint system the belt lock button needs an adult force to open this is for the safety of the child so they cannot open it 12
The restraint system length can be adjusted by adjusting buckle a and b to adjust buckles a b hold the buckle as shown in pic 1 by pressing the red button the belt loosens by pulling the buckle upwards to tighten the restraint system just pull end of the belt straps pic 2 move the buckle c up to secure the belt so it cannot fall down from the child s shoulders pic 3 12
Where to push 12
Zenith relax 12
How to remove the seat 13
Reclinable function 13
The seat 1 is easy to remove from the bicycle when not in use press the cover of the bracket and pull the seat bar free from the bracket 6 13
To recline the seat press the reclining knob 9 down and at the same time twist to the required position 13
Zenith relax 13
Adjust the restraint system 2 to ensure the child is snugly restrained in the seat adjust the foot rests 4 and fasten foot straps 14
Before embarking on a bicycle trip 14
Warning check that the green safety indicators 6d of the bracket are visible ensure the rider and child always wear approved and properly fitted bicycle helmets never leave a child unattended in the bicycle child seat never leave a child in the bicycle child seat with the bicycle supported only by the kick stand 14
Zenith relax 14
Extra fastening bracket 15
Problem 15
Problem solving 15
Should your seat be too close to the carrier wheel when mounted there is an extra bar available which may solve your problem please contact your bicycle dealer 15
Solution 15
With an extra bracket 6 you can easily move one seat between two bicycles hamax fastening bracket 6 is available in two version standard and lockable art nr 604001 standard bracket art nr 604002 lockable bracket 15
Zenith relax 15
Carrier adapter 16
Read more about the carrier adapters at www hamax com child bike seat caress collection zenith with carrier adapter full assembly instructions follows the product when purchased and can also ble downloaded from www hamax com 16
You may also mount the seat on a bicycle luggage carrier by means of a carrier adapter this can be useful if your bicycle has a frame diameter outside the range of 28 40 mm or if you have an electrical bicycle 16
Zenith relax 16
