Specications 11
Specications
Power supply
• 90 watt automatic voltage-sensing power supply
• 120 watt automatic voltage-sensing power supply
Storage drives
Up to two storage drives
Video features
• HDMI-in connector
• HDMI-out connector
Audio features
The integrated audio card supports the following:
• Headset connector
• Integrated microphone
• Internal speaker
The optional discrete audio card provides an enhanced audio experience
and extended capabilities.
Input/Output (I/O) features
• Audio connectors (headset connector and integrated microphone
connector)
• Card reader slot
• Ethernet connector
• HDMI-in connector
• HDMI-out connector
• Headset connector
• USB connectors
Expansion
• Memory slots
• Optical drive (optional)
• Storage drive bay
