Overview 7
Adjusting the monitor stand
Note
The monitor stand is available only on some models.
Adjust the vertical position of the computer between 5° forward
and 24° back.
Adjust the angle of the computer between 45° to the left and 45°
to the right.
Adjusting the UltraFlex II Stand
Note
The UltraFlex II Stand is available only on some models.
Adjust the vertical position of the computer between 5° forward
and 61° back.
