Specications 12
Network features
• Ethernet LAN
• Wireless LAN (optional)
• Bluetooth (optional)
Physical dimensions
• Width: 526 mm (20.7 inches)
• Height: 339 mm (13.3 inches)
• Depth: 47 mm (1.9 inches)
Weight (without the package)
Maximum conguration as shipped: 7.5 kg (16.5 lb)
