![Makita GA5034 [4/72] Specifications](/views2/1300921/page4/bg4.png)
4
ENGLISH (Original instructions)
Explanation of general view
1 Shaft lock
2 Lock-off lever
3 Switch lever
4 Wheel guard
5 Screw
6 Bearing box
7Lever
8 Lock nut
9 Depressed center grinding
wheel/ Multi-disc
10 Inner flange
11 Lock nut wrench
12 Abrasive cut-off wheel/diamond
wheel
13 Wheel guard for abrasive cut-off
wheel/diamond wheel
14 Exhaust vent
15 Inhalation vent
SPECIFICATIONS
Model GA4034 GA4534 GA5034
Depressed center wheel diamiter........................... 100 mm 115 mm 125 mm
Spindle thread .......................................................M10 M14 M14
Rated speed (n) / No load speed (n
0
) .................... 11,000 min
-1
11,000 min
-1
11,000 min
-1
Overall length ........................................................ 265 mm 265 mm 265 mm
Net weight ............................................................. 1.8 kg 1.9 kg 1.9 kg
Safety class ........................................................... /II /II /II
• Due to our continuing program of research and devel-
opment, the specifications herein are subject to change
without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
Intended use
The tool is intended for grinding, sanding and cutting of
metal and stone materials without the use of water.
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated in accordance with European Standard
and can, therefore, also be used from sockets without
earth wire.
GEA010-1
General Power Tool Safety Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future refer-
ence.
GEB033-3
GRINDER SAFETY WARNINGS
Safety Warnings Common for Grinding, Sanding,
Wire Brushing, or Abrasive Cutting-Off Operations:
1. This power tool is intended to function as a
grinder, sander, wire brush or cut-off tool. Read
all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
2. Operations such as polishing are not recom-
mended to be performed with this power tool.
Operations for which the power tool was not
designed may create a hazard and cause personal
injury.
3. Do not use accessories which are not specifi-
cally designed and recommended by the tool
manufacturer. Just because the accessory can be
attached to your power tool, it does not assure safe
operation.
4. The rated speed of the accessory must be at
least equal to the maximum speed marked on
the power tool. Accessories running faster than
their rated speed can break and fly apart.
5. The outside diameter and the thickness of your
accessory must be within the capacity rating of
your power tool. Incorrectly sized accessories can-
not be adequately guarded or controlled.
6. The arbour size of wheels, flanges, backing pads
or any other accessory must properly fit the
spindle of the power tool. Accessories with arbour
holes that do not match the mounting hardware of
the power tool will run out of balance, vibrate exces-
sively and may cause loss of control.
7. Do not use a damaged accessory. Before each
use inspect the accessory such as abrasive
wheels for chips and cracks, backing pad for
cracks, tear or excess wear, wire brush for loose
or cracked wires. If power tool or accessory is
dropped, inspect for damage or install an
undamaged accessory. After inspecting and
installing an accessory, position yourself and
bystanders away from the plane of the rotating
accessory and run the power tool at maximum
no-load speed for one minute. Damaged accesso-
ries will normally break apart during this test time.
8. Wear personal protective equipment. Depending
on application, use face shield, safety goggles
or safety glasses. As appropriate, wear dust
mask, hearing protectors, gloves and workshop
apron capable of stopping small abrasive or
workpiece fragments. The eye protection must be
capable of stopping flying debris generated by vari-
ous operations. The dust mask or respirator must be
capable of filtrating particles generated by your oper-
ation. Prolonged exposure to high intensity noise
may cause hearing loss.
