Makita CA5000XJ [8/60] Functional description

8 ENGLISH

8. ALWAYS hold the tool rmly with both hands.

NEVER place your hand, leg or any part of your

body under the tool base or behind the saw,

especially when making cross-cuts. If kickback

occurs,thesawcouldeasilyjumpbackwardsover

yourhand,leadingtoseriouspersonalinjury.

►Fig.4

9. Never force the saw. Push the saw forward at a

speed so that the blade cuts without slowing.

Forcing the saw can cause uneven cuts, loss of

accuracy, and possible kickback.

Guard function

1. Check guard for proper closing before each

use. Do not operate the saw if guard does not

move freely and enclose the blade instantly.

Never clamp or tie the guard so that the blade

is exposed. If saw is accidentally dropped, guard

may be bent. Check to make sure that guard

moves freely and does not touch the blade or any

other part, in all angles and depths of cut.

Check the operation and condition of the guard

return spring. If the guard and the spring are not

operating properly, they must be serviced before

use. Guard may operate sluggishly due to damaged

parts, gummy deposits, or a build-up of debris.

Assure that the base plate of the saw will not

shift while performing the “plunge cut” when the

blade bevel setting is not at 90 °. Blade shifting

sideways will cause binding and likely kick back.

4. Always observe that the guard is covering the

blade before placing saw down on bench or

oor. An unprotected, coasting blade will cause

the saw to walk backwards, cutting whatever is in

its path. Be aware of the time it takes for the blade

to stop after switch is released.

Additional safety warnings

1. Use extra caution when cutting damp wood,

pressure treated lumber, or wood containing

knots. Maintain smooth advancement of tool with-

out decrease in blade speed to avoid overheating

the blade tips.

2. Do not attempt to remove cut material when

blade is moving. Wait until blade stops before

grasping cut material. Blades coast after turn off.

3. Avoid cutting nails. Inspect for and remove all

nails from lumber before cutting.

4. Place the wider portion of the saw base on

that part of the workpiece which is solidly

supported, not on the section that will fall off

when the cut is made. If the workpiece is short

or small, clamp it down. DO NOT TRY TO HOLD

SHORT PIECES BY HAND!

►Fig.5

5. Before setting the tool down after completing a

cut, be sure that the guard has closed and the

blade has come to a complete stop.

6. Never attempt to saw with the circular saw

held upside down in a vise. This is extremely

dangerous and can lead to serious accidents.

►Fig.6

Some material contains chemicals which may be

toxic. Take caution to prevent dust inhalation and

skin contact. Follow material supplier safety data.

8. Do not stop the blades by lateral pressure on

the saw blade.

9. Do not use any abrasive wheels.

10. Only use the saw blade with the diameter that

is marked on the tool or specied in the man-

ual. Use of an incorrectly sized blade may affect

the proper guarding of the blade or guard opera-

tionwhichcouldresultinseriouspersonalinjury.

11. Keep blade sharp and clean. Gum and wood

pitch hardened on blades slows saw and

increases potential for kickback. Keep blade clean

byrstremovingitfromtool,thencleaningitwith

gum and pitch remover, hot water or kerosene.

Never use gasoline.

12. Wear a dust mask and hearing protection when

use the tool.

SAVE THESE INSTRUCTIONS.

WARNING: DO NOT let comfort or familiarity

with product (gained from repeated use) replace

strict adherence to safety rules for the subject

product. MISUSE or failure to follow the safety

rules stated in this instruction manual may cause

serious personal injury.

FUNCTIONAL

DESCRIPTION

CAUTION: Always be sure that the tool is

switched off and unplugged before adjusting or

checking function on the tool.

Quick stop for 3, 4, or 6 mm board

thickness groove cutting

By turning the quick stop, you can choose the appro-

priate depth of groove cutting for 3, 4, or 6 mm board

thickness swiftly.

The number, seen from the handle side, indicates the

workpiece board thickness.

Forneadjustmentofdepthofgroove,usethedepth

adjustingknob.

►Fig.7: 1. Quick stop 2.Depthadjustingknob

0 mm depth is set properly when the tool is shipped

from the factory, but if you changed the depth of groove

bytheadjustingknob,renethe0mmdepthasfollows:

1. Turn the quick stop to 0 mm.

2. Turnthedepthadjustingknobtoadjustthedepth.

3. Make sure that the blade does not make any

contact with work piece.

4. Holdthetoolrmlywithonehandonthefrontgrip

and the other on the tool handle. Push in the lock-off

button, and turn the tool on.

5. Slowly press down the saw head fully, and check

whether the groove cutter blade does not contacts but

almost touches the workpiece. If not, stop the tool and

wait until the groove cutter blade stops completely, and

adjustthedepthbyturningthedepthadjustingknob

again.
