46
User Controls
Input Source
Use this option to enable / disable input sources. Press ▲ or ▼
to select a source, then press ◄ or ► to enable / disable it. Press
“ENTER” to nalize the selection. The projector will not search
inputs that are de-selected.
Options |
Input Source
Note
Note
If all sources are
deselected, the
projector cannot display
any images. Always
leave at least one
source selected.
