English
7
Introduction
Package Overview
Unpack and inspect the box contents to ensure all parts
listed below are in the box. If something is missing,
please contact Optoma customer service.
Projector with lens cap Power Cord 1.8m 15 pin D-sub VGA Cable
Remote Control 2 x AAA Batteries Carrying Case
Documentation :
User's Manual
Warranty Card
Quick Start Guide
WEEE Card
Note
Note
Due to different
applications in each
Country, some regions
may have different
accessories.
