16
Specifications
Continued from previous page
WLAN & Bluetooth
®
(Optional)
y Intel
®
Dual Band Wireless-AC 8260 module (optional)
Supports M.2 (Key E) interface
Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz,
5GHz) up to 867 Mbps speed.
Supports Dual Mode Bluetooth
®
2.1, 2.1+EDR, 3.0, 4.0,
BLE, 4.2
USB
y Intel
®
C232 Chipset
1x USB 3.1 Gen1 (SuperSpeed USB) Type-C port on the
back panel
5x USB 3.1 Gen1 (SuperSpeed USB) ports (3 ports on the
back panel, 2 ports available through the internal USB
3.1 Gen 1 connector)
4x USB 2.0 (High-speed USB) ports (2 ports on the back
panel, 2 ports available through the internal USB 2.0
connectors)
Audio
y Realtek
®
ALC892 Codec
y 7.1-Channel High Definition Audio
LAN
1x Intel
®
I219-V Gigabit LAN controller
Back Panel
Connectors
y 1x PS/2 mouse port
y 1x PS/2 keyboard port
y 1x Clear CMOS button
y 1x USB 3.1 Gen1 Type-C port
y 3x USB 3.1 Gen1 ports
y 1x LAN (RJ45) port
y 2x USB 2.0 ports
y 6x audio jacks
Continued on next page
