Specifications
Specifications
CPU
Supports Intel
®
Xeon
®
E3-1200 v5 series processors, Core™
i3 processors, and Intel
®
Pentium
®
and Celeron
®
processors
for Socket LGA1151
Chipset Intel
®
C232 Chipset
Memory
y 4x DDR4 memory slots, support up to 64GB
Supports DDR4 2133 MHz*
y Dual channel memory architecture
y Supports ECC, un-buffered memory*
y Supports Intel
®
Extreme Memory Profile (XMP)**
* For the latest information about memory, please visit http://www.msi.com
** DDR4 2133 MHz and higher memory modules will only run at maximum of
DDR4 2133 MHz on XMP mode due to Intel
®
chipset limitation.
Expansion Slots
y 2x PCIe 3.0 x16 slots (support x16/x4 modes)*
y 2x PCIe 3.0 x1 slots
y 2x PCI slots**
y 1x M.2 Wi-Fi/ Bluetooth
®
module slot (Key E)
* PCI_E4 slot will be unavailable when installing the M.2 PCIe module in M.2
slot (Key M, M2_1).
** No support PCI wake-up on S3, S4 & S5
Multi-GPU
y Supports 2-Way AMD
®
CrossFire
™
Technology
Storage
Intel
®
C232 Chipset
y 6x SATA 6Gb/s ports*
Supports RAID 0, RAID 1, RAID 5 and RAID 10
Supports Intel
®
Rapid Storage Technology enterprise
y 1x M.2 slot (Key M)*
Supports up to PCIe 3.0 x4 and SATA 6Gb/s
Supports 2242/ 2260/ 2280/ 22110 storage devices
Supports PCIe 3.0 x4 NVMe Mini-SAS SSD with Turbo U.2
Host Card**
* SATA6 port will be unavailable when installing the M.2 SATA module in M.2
slot (Key M, M2_1). PCI_E4 slot will be unavailable when installing the M.2
PCIe module in M.2 slot (Key M, M2_1).
** The Turbo U.2 Host Card is not included, please purchase separately.
Continued on next page
