25
Overview of Components
Port Name Port Type Page
CPUFAN1~2, SYSFAN1~3 Fan Connectors 35
CPU Socket LGA1151 CPU Socket 27
DIMM1~4 DIMM Slots 28
EZ Debug LED Debug LED indicators 38
JAUD1 Front Audio Connector 34
JBAT1 Clear CMOS (Reset BIOS) Jumper 37
JCI1 Chassis Intrusion Connector 38
JCOM1 Serial Port Connector 36
JFP1, JFP2 Front Panel Connectors 33
JLPT1 Parallel Port Connector 36
JPWR1~2 Power Connectors 32
JTPM1 TPM Module Connector 37
JUSB1 USB 2.0 Connector 33
JUSB2 USB 3.1 Gen1 Connector 34
M2_1 M.2 Slot (Key M) 31
M2_2 M.2 slot (Key E) 26
PCI_E1~E4, PCI1~2 PCIe and PCI Expansion Slots 29
SATA1~6 SATA 6Gb/s Connectors 30
