5
English
Z270 SuperCarrier
Rear Panel
I/O
•
2 x Antenna Ports
•
1 x PS/2 Mouse/Keyboard Port
•
1 x HDMI Port
•
1 x DisplayPort 1.2
•
2 x Intel® underbolt
TM
3 (Compatible with USB 3.1 and
USB-C Display)*
* Supports USB PD 2.0 up to 12V@3A (36W) charging
* Hot Plug is supported on Win 10 only
•
1 x Optical SPDIF Out Port
•
2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))
•
4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))**
** Ultra USB Power is supported on USB3_34 ports.
** ACPI wake-up function is not supported on USB3_34 ports.
•
3 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED
LED)
•
1 x Clear CMOS Switch
•
HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone (Gold Audio Jacks)
Storage
•
6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology
15 and Intel Smart Response Technology), NCQ, AHCI and
Hot Plug*
* If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will
be disabled.
* M2_2, SATA3_4 and SATA3_5 share lanes. If either one of
them is in use, the others will be disabled.
* If M2_3 is occupied by a SATA-type M.2 device, SATA3_3
will be disabled.
•
4 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, sup-
port NCQ, AHCI and Hot Plug
•
2 x SATA Express 10 Gb/s Connectors**
** Support to be announced
•
3 x Ultra M.2 Sockets, support type 2230/2242/2260/2280
M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module
up to Gen3 x4 (32 Gb/s)***
** Supports Intel® Optane
TM
Technology
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
